Taking Density Measurement
1. The gauge display prompts you to lower the source rod to
the desired measurement depth and press ENTER/START.
2. Move the rod to the desired depth position between
backscatter and 12 inches. Be sure the rod is seated
properly in the position notch.
3. Gently slide the gauge to the right until the source rod is in
contact with the side of the hole.
4. Press ENTER to start the measurement. The gauge displays:
NOTE
If the depth sensor detects an invalid depth the following displays.
Reposition the rod at the correct depth. If the error continues, use the
gauge in Manual Depth mode (see Setting the Automatic or Manual
Depth on page 3–12) until it can be serviced by a Troxler authorized
service center. In the Manual Depth mode, you will be prompted to
enter the depth.
5. After the measurement completes, raise the handle to the
SAFE position and follow the instructions on the display.
