4–4
PRINTER
Figure 4–2 shows the front panel of the oven printer. As shown in
the figure, the status LED and paper feed button are located in the
upper righ
t corner of the printer.
The status LED is green when the printer is powered on. In the
event of a print error, the LED is amber.
The paper feed button activates the paper feed mechanism. Paper
will continue to feed until the button is released.
NOTE
The paper feed button is disabled during normal
printing.
For information on replacing the printer paper and cartridge, refer to
Appendix A.
STATUS LED PAPER FEED
FINGER LOCATIONS FINGER LOCATIONS
TO OPEN DOOR TO OPEN DOOR
Figure 4–2. Printer Front Panel
