Troxler NTO series User Manual

4–10
8. Place the basket cover over the top sample basket as shown in
Figure 4–3. Secure the sample baskets and cover to the catch
pan with the lock arms
. Ensure that the lock arms fully engage
the slots in the top sample basket.
9. Use the external scale to weigh the sample, sample baskets,
catch pan, and sample basket cover. Record the total mass (W
T
).
10. Press 〈START〉 to begin the process.
11. The oven requests the sample mass (W
S
) as shown below. To
determine the sample mass, subtract the basket assembly mass
(W
B
) recorded in step 4 from the total mass (W
T
) recorded in
step 9 (W
S
= W
T
– W
B
). Enter the sample mass and press
〈ENTER〉.
Enter Sample
Mass g
then press ENTER
BASKET
COVER
SAMPLE
BASKETS
CATCH
PAN
LOCK ARMS
Figure 4–3. Sample Basket Assembly
