D301087 0308 - BL20 CANopen 4-219
I/O-Module Objects
4
6 operating mode
wrong
The value (XXXX11) for selecting the
operating mode is incorrect.
Permissible values for count mode:
000000 = Continuous count
000001 = Single-action count
000010 = Periodical count
Permissible values for measurement
mode:
100000 = Frequency measurement
100001 = Revolutions measurement
100010 = Period duration measure-
ment
7 Measurement
mode
This message is always shown in
conjunction with other diagnostics
messages and indicates that
messages refer to an active measure-
ment mode.
Table 150:
Meaning of the
data bits in
measurement
mode
Bit Diagnostics
message
Meaning
