IAS VNO
Maximum structural
cruising speed
Set to match limits: 40 to 555
(150*) in IAS UNITS
IAS VNE
Never exceed speed
Set to match limits: 40 to 555
(175*) in IAS UNITS
IAS VMC
Minimum control
airspeed with the critical
engine inoperative
Set to match limits: 40 to 555
or disabled* in IAS UNITS
IAS VYSE
Speed for best rate of
climb OEI (single engine)
Set to match limits: 40 to 555
or disabled* in IAS UNITS
BARO UNITS
Altimeter barometric
units
Inches of Mercury* (INHG),
Millibars (MB), hectopascals
(HPA)
TEMP UNITS
OAT units
Celsius* (C) or Fahrenheit (F)
GPS NAV SRC
Serial GPS format
NONE, SERIAL 1*, SERIAL
2
SERIAL 1
GPS serial input
NONE, AV 9600*, NMEA
4800, NMEA 9600, BCNX
GPS
SERIAL 2
Auxiliary serial input
NONE*, BEACON X, AV-
APA, AEROCRUZE, PRO
PILOT
SERIAL 3
System serial input
NONE, AVLINK*, EFIS,
EFIS+AVLINK
SERIAL 4
AV-Mag serial input
NONE*, AVMAG
STATE SYNC
Synchronization of pilot
settings across multiple
AV-30 using AV-HSI or
between an AV-30 and
EFIS.
Source: None, AV-HSI*, EFIS
Heading Bug: No, Yes*
OBS: No, Yes*
Set Altitude: No, Yes*
Set Vertical Speed: No, Yes*
Autopilot Mode: No, Yes*
CDI Source: No, Yes*
Baro Setting: No, Yes*
OAT: No, Yes*
DG: No, Yes*
Alerts: No, Yes*
AID MODE
AHRS aiding mode
NONE
[1]
, MAG1*, MAG2,
AVMAG
[2]
AVMAG INSTL
AV-Mag Installation
See Table 13-2 for submenu
description
Record settings in
Table 13-2
AVMAG CAL
Calibrates external
magnetometer
Perform calibration after
installation  only available
for units with external
magnetometer
AVMAG YAW
AV-Mag installed Yaw
angle trim
Trim as needed: ±15 Degrees
(0*)
MAG MONITOR
Magnetometer monitor
Push to view
VIBE MONITOR
Vibration monitor
Push to view
GYRO CAL
Calibrates aircraft gyros
Perform at installation or
software update
INT MAG CAL
Calibrates internal
magnetometer
Perform calibration after
installation  only available
for units with internal
magnetometer. Disabled
