uAvionix AV-30-E - Power Input (Required)

UAV-1004234-001, AV-30-E Installation Manual 24
Rev H
Indicated Airspeed (Textual)
✓

Pitot / Static
V-Speeds (Graphical)
✓

Pitot / Static
Baro Altitude (Textual)
✓
✓
Pitot / Static
Angle Of Attack (Graphical)
✓

Pitot / Static
Vertical Trend (Graphical)
✓

Pitot / Static
Vertical Speed (Textual)
✓
✓
Pitot / Static
Set Altitude (Textual)
✓
✓
None
Heading (Textual)
✓
✓
Pitot / Static
Bus Voltage (Textual)
✓
✓
None
G Load (Textual)
✓
✓
None
Outside Air Temp (Textual)
✓
✓
OAT Probe
True Airspeed (Textual)
✓
✓
Pitot / Static / OAT Probe
Density Altitude (Textual)
✓
✓
Pitot / Static / OAT Probe
GPS Navigation / Waypoint Data
Textual Nav Data
✓
✓
GPS Navigator
Graphical Nav Data

✓
GPS Navigator
Heading Bug
Hdg Bug (Ref Only if no AP)
✓
✓
None
Set Vertical Speed Bug
SVS Bug (Graphical)
✓

Autopilot
Audio and Visual Alerting
AoA Alerting
✓

Pitot / Static
G Limit Alerting
✓

None
Excessive Roll Alerting
✓

None
Misc.
Internal Battery Operation
✓
✓
Pitot / Static
Auto / Manual Brightness
✓
✓
None
Transponder Control
✓
✓
Transponder serial / Pitot /
Static
Traffic display
✓
✓
AV-Link / GDL-90 / Pitot /
Static
Internal Magnetometer aid
✓
✓
Optional hardware / Pitot /
Static
External Magnetometer aid
✓
✓
AV-Mag / Pitot / Static
9.2.1 Power Input (Required)
Power input is required in both AI, DG and MFD configurations and each
unit has a dedicated circuit breaker. The power input is internally

processor-controlled switch. This architecture allows the unit to continue
operation if external power fluctuates or is completely lost. Input range is
compatible with both 12V and 24V aircraft.
