11.3.4 AV-Mag Software
The software contained in the AV-Mag device is identified by electronic
marking. Software version information is sent in a serial message after
power-up. The first screen of the AV-Mag installation menu shows the
current AV-Mag software version and CRC (see Section 11.3.8). If AV-
Mag is not properly connected, the
11.3.5 AV-Mag Installation Overview
An overview of the installation process is provided below. Further detail
for the process may be found starting in Section 11.3.8.
1. Configure the AV-30
a. In the AV-30 installation menu, set SERIAL 4 to AVMAG to
enable the AV-Mag.
b. Enter the AV-Mag installation menu (AVMAG INSTL) found
in the AV-30 installation menu.
2. Wire and mount the AV-Mag
a. Identify a potential mounting location in the tail or wings.
b. Run wires from the AV-30 to the mounting location and
connect to the AV-Mag.
c. Check the mounting location for magnetic interference using
the interference monitor in the AVMAG INSTL menu.
• If magnetic interference is excessive at the mounting
location, select a different mounting location.
