uAvionix AV-30-E - 10.9 Unit Pinout

UAV-1004234-001, AV-30-E Installation Manual 44
Rev H
10.9 Unit Pinout
Table 10-3 - Connector Pinout
Pin
Function
Type
Comment
1
Power
Power
+12 to +28 VDC
2
Navigation In
Input
GPS OR AV-HSI RS-232
Input
3
Navigation Out
Output
AV-HSI RS-232 Output
4
Serial 2
Input
Transponder OR AV-APA
5
Serial 2
Output
Transponder OR Autopilot
RS-232 OR AV-APA
6
Serial 4
Input
AV-Mag Data
7
OAT Supply
Output
White Probe Wire
8
Serial 3
Input
Software Update Harness or
Third Party EFIS
9
Ground
Power
Aircraft Ground
10
Aux Power Ret
Power
AV-Mag / Auxiliary Power
return
11
Audio H
Output
Audio Alerts hi
12
Audio L
Output
Audio Panel lo
13
Aux Power Out
Power
AV-Mag / Auxiliary Power
14
OAT Return
Input
White / Blue Probe Wire
15
Serial 3
Output
Software Update Harness or
Third Party EFIS
