UAV-1004234-001, AV-30-E Installation Manual 90
Rev H
PIN
Function
DB9 Pin 1
No Connect
DB9 Pin 2
No Connect
DB9 Pin 3
A429 RX Channel 2 A
DB9 Pin 4
A429 RX Channel 2 B
DB9 Pin 5
A429 RX Channel 1 A
DB9 Pin 6
A429 TX A
DB9 Pin 7
A429 TX B
DB9 Pin 8
A429 RX Channel 1 B
DB9 Pin 9
Shield Ground
11.6.3 AV-HSI Installation Overview
An overview of the installation process is provided below. Further detail
for the process may be found later in this document.
1. Wire and mount the AV-HSI
a. Identify the mounting location.
• The AV-HSI should be mounted to something rigid in a
location that does not interfere with flight control
movement.
• The AV-HSI is not waterproof; it must be mounted in a
dry location.
b. Wire the AV-HSI to the AV-30-E(s) and navigators as and
autopilot as described below. Detailed information about
your navigator can be found in the navigator installation
manual.
c. Mount the AV-HSI using appropriate fasteners. Fastener
length and type will vary by installation and are therefore not
provided in the installation kit. Use AC 43.13-1B for
guidance.
2. Configure the AV-30s and AV-HSI
3. Perform a ground checkout
