UAV-1004234-001, AV-30-E Installation Manual 104
Rev H
Table 13-2 - AV-Mag Submenu
Checklist of systems to
exercise and monitor for
excessive interference
with the AV-Mag
LIGHTS, AVIONICS, CONTROLS,
OTHER, ALL ON, REVIEW
Orientation of the installed
AV-Mag
See Table 11-5 for more details
Angles of the AV-30
instrument in the
stationary aircraft.
No user entry. Information for AV-
Mag installation only. AV-Mag
should be installed as closely as
possible to the AV-30 angles.
Roll angle of the AV-Mag
as mounted in the
stationary aircraft
Trim as needed: ±10 degrees
(0.0*) May be automatically self-
measured by AV-Mag hardware
Pitch angle of the AV-Mag
as mounted in the
stationary aircraft
Trim as needed: ±10 degrees
(0.0*) May be automatically self-
measured by AV-Mag hardware
Option to save changes to
input roll and pitch angles
YES, Y/N?, NO. Only save when
installing and a valid hand
measurement of the angles AS
-
as
this will trigger re-calculations that
will be invalid if the aircraft has
been moved since the hand
measurement.
Final screen of installation
submenu. The next step
of installation is to run the
calibration procedure.
* Initial factory value
13.1 Mandatory Settings
The following settings are mandatory for each installation.
13.1.1 Unit Function
• Set to AI if installation is replacing an existing Attitude Indicator.
• Set to DG if installation is replacing and existing Direction Indicator.
• Set to either when installed as a non-required instrument. In this
mode, this setting is the initial default operating mode if the function
lock below is not set to locked. With this setting, the pilot may toggle
the mode during flight.
