Table 11-5 - AV-Mag Orientation Options
Menu Option
Label direction
Wire direction
LUP+WAFT
Upward (facing up)
Toward tail (wires aft)
LUP+WFOR
Upward
Toward nose (wires fore)
LUP+WLT
Upward
Toward left wingtip (wires
port)
LUP+WRT
Upward
Toward right wingtip (wires
starboard)
LDN+WAFT
Downward (facing down)
Toward tail
LDN+WFOR
Downward
Toward nose
LDN+WLT
Downward
Toward left wingtip
LDN+WRT
Downward
Toward right wingtip
LRT+WAFT
Right wingtip (facing starboard)
Toward tail
LRT+WFOR
Right wingtip
Toward nose
LRT+WUP
Right wingtip
Toward sky (wires
upward)
LRT+WDN
Right wingtip
Toward ground (wires
downward)
LLT+WAFT
Left wingtip (facing port)
Toward tail
LLT+WFOR
Left wingtip
Toward nose
LLT+WUP
Left wingtip
Toward sky
LLT+WDN
Left wingtip
Toward ground
LFOR+WUP
Forward (facing nose)
Toward sky
LFOR+WDN
Forward
Toward ground
LFOR+WLT
Forward
Toward left wingtip
LFOR+WRT
Forward
Toward right wingtip
LAFT+WUP
Aft (facing tail)
Toward sky
LAFT+WDN
Aft
Toward ground
LAFT+WLT
Aft
Toward left wingtip
LAFT+WRT
Aft
Toward right wingtip
