uAvionix AV-30-E - AV-HSI Specifications

UAV-1004234-001, AV-30-E Installation Manual 88
Rev H
MGL
N16 (requires separate control head)
VAL
NAV 2000
11.6.2 AV-HSI Specifications
Table 11-11 - AV-HSI Specifications
Characteristics
Specifications
Part Number
UAV-1007412-001
Width
2.3 Inches
Height
.614 Inches
Depth
2.3 Inches
Weight
1.8 oz (50 grams)
Operating temperature range
-40°C to +70°C
Input voltage range
+10 to +32 VDC
14V current
.02 A typical
28V Current
.01 A typical
Figure 28 - AV-HSI Mechanical Drawing
