UAV-1004234-001, AV-30-E Installation Manual 89
Rev H
Table 11-12 AV-HSI Pinout
PIN
Function
DB15 Pin 1
Power
DB15 Pin 2
RS-232 Port 1 In
DB15 Pin 3
RS-232 Port 1 Out
DB15 Pin 4
RS-232 Port 2 In
DB15 Pin 5
RS-232 Port 2 Out
DB15 Pin 6
RS-232 Port 3 In
DB15 Pin 7
RS-232 Port 3 Out
DB15 Pin 8
RS-232 Port 4 In
DB15 Pin 9
Ground
DB15 Pin 10
No Connect
DB15 Pin 11
No Connect
DB15 Pin 12
No Connect
DB15 Pin 13
No Connect
DB15 Pin 14
No Connect
DB15 Pin 15
RS-232 Port 4 Out
