10 Equipment Installation
10.1 Overview
Installation consists of the following steps:
• Remove / relocate any legacy instrumentation
• Add or locate an appropriate power source / breaker
• Wire power and system interfaces as needed
• Mount the unit to the instrument panel with supplied screws
• Apply power and perform setup
• Connect pitot and static to both AI and DG. Perform leak check
after installation
• (Optional) Install the AV-Mag external magnetometer and perform
calibration
10.2 Supplied Components
Table 10-1 - Supplied Components
Component
Part Number
Description
AV-30-E Unit
UAV-1004035-001
AV-30-E Unit without
Internal
Magnetometer
UAV-1004035-002
AV-30-E Unit with
Internal
Magnetometer
AV-30-E Installation Kit
UAV-1004091-001
Installation Kit
AV-30-E Operating
Software
UAV-1004037-009
AV-30-E Operating
Software v2.4.1
(Optional) AV-Link-E
UAV-1004413-001
AV-Link Wi-Fi Bridge
(Optional) AV-Mag-E
UAV-1006321-001
AV-Mag External
Magnetometer
(Optional) AV-APA
UAV-1006839-001
AV-APA Analog Port
Adapter
(Optional) AV-HSI
UAV-1007412-001
AV-HSI ARINC 429
Adapter
The AV-30-E Installation Kit includes the following:
• 6-32 mounting screws
