uAvionix AV-30-E - AV-APA Specifications

UAV-1004234-001, AV-30-E Installation Manual 70
Rev H
11.4.2 AV-APA Specifications
Table 11-7 - AV-APA Specifications
Characteristics
Specifications
Part Number
UAV-1006839-001
Width
2.2 Inches
Height
0.8 Inches
Depth
2.6 Inches
Weight
1.7 oz (48 grams)
Operating temperature range
-40°C to +70°C
Input voltage range
+10 to +32 VDC
14V current
.024 A typical
28V Current
.012 A typical
Figure 24 - AV-APA Mechanical Drawing
