UAV-1004234-001, AV-30-E Installation Manual 71
Rev H
AV-30 Connector J2 (male)
Autopilot Connector J8 (female)
Figure 25 - AV-APA Connectors
Wiring the AV-APA backward may cause damage to the AV-
APA, AV-30, and Autopilot. Take note of the connector
orientation and gender to ensure the proper connectors are
used.
