uAvionix AV-30-E - Serial Inputs

UAV-1004234-001, AV-30-E Installation Manual 106
Rev H
Set the TAS units to owner / pilot preference.
Set the Baro units to match that of the existing altimeter.
Set OAT units to owner / pilot preference.
13.1.8 Serial Inputs
GPS NAV SRC
Multiple serial ports support GPS sources. Set to the serial port on which
your GPS source is installed.
Value
GPS Source
NONE
None available
SERIAL 1
Specified in SERIAL 1 setting
SERIAL 2
Specified in SERIAL 2 setting
SERIAL 1
This serial port corresponds to DB-15 pin 2 and 3. Set according to the
type of the installed GPS navigator on this port.
Most handheld GPS navigators produce output in NMEA format while
most panel-mounted navigators produce Aviation format.
A tailBeaconX can also supply GPS data. To use it as a GPS source
when BCNX GPS is selected, the tailBeaconX must share its serial
connection with a second AV-30. The second AV-30 must have SERIAL
2 set to BEACON X. See Figure 21 - Parallel tailBeaconX GPS
Connections for a diagram of the required connections and settings in
this configuration.
Value
Serial 1 Source
NONE
None available
AV 9600
Aviation format (9600 bps)
NMEA 4800
NMEA format (4800 bps)
