UAV-1004234-001, AV-30-E Installation Manual 107
Rev H
NMEA 9600
NMEA format (9600 bps)
BCNX GPS
tailBeaconX is installed (see Figure 21)
AV-HSI
ARINC-429 navigator connected to AV-
HSI
SERIAL 2
This serial port corresponds to DB-15 pins 4 and 5. This serial port
supports a tailBeaconX or autopilot connection.
If using the AV-30 as a control head for a tailBeaconX, set SERIAL 2 to
BEACON X. Otherwise, set SERIAL 2 according to the autopilot
connection (or NONE if nothing is connected).
Value
Serial 2 Source
NONE
None available
BEACON X
tailBeaconX is installed on
SERIAL 2
AV-APA
AV-APA is installed on SERIAL 2
AEROCRUZE
AeroCruze 100/ xCruze 100
/TruTrak Vizion autopilot
PRO PILOT
Trio Pro Pilot
SERIAL 3
Serial 3 is the system serial port. If using the AV-Link, set SERIAL 3 to
AVLINK to enable MFD page. If connecting to a third-party EFIS, set to
EFIS. If using an AV-Link and connecting a third-party EFIS, set to
EFIS+AVLINK.
Value
Serial 3 Source
NONE
None available
AVLINK
AV-Link is installed, MFD enabled
EFIS
Third-party EFIS connected
