uAvionix AV-30-E - 11.3 AV-Mag External Magnetometer

UAV-1004234-001, AV-30-E Installation Manual 54
Rev H
Figure 21 - Parallel tailBeaconX GPS Connections
11.2.1 Transponder Control

See AV-30--1004233-
001 for transponder control interface configuration.
11.2.2 Transponder Testing with AV-30
Ground test mode may be initiated from the AV-30 via the following:
• Set tailBeaconX in STBY mode using the AV-30.
• Open the AV-30 installation menu and select BEACONX GTM
• tailBeaconX will now respond to All-Calls on transponder test sets.
• When test is complete, cycle tailBeaconX power to exit test mode.
11.3 AV-Mag External Magnetometer
11.3.1 Magnetometer Overview
AV-Mag external magnetometer (P/N UAV-1006321-001) is a 3-axis
electronic compass. It can precisely 
and aid the AV-30 gyroscopic heading measurement, improving long-
term accuracy.
AV-30
GPS NAV SRC: SERIAL 2
SERIAL 2: BEACON X
AV-30
GPS NAV SRC: SERIAL 1
SERIAL 1: BCNX GPS
4
2
5
tailBeaconX
Gray (transmit data)
Orange (receive data)
