UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
155
Modulation depth 0.00%-100.00%
QAM Modualtion
IQ map
QAM4，QAM8，QAM16，QAM32，QAM64，QAM128，QAM256
Modulation source
PN3、PN5、PN7、PN9、PN11、PN13、PN15、PN17、PN21、PN23
、
PN25
、
PN27
、
PN29
、
PN31
、
PN33
Modulation rate 1μbps-2Mbps 1μbps-1Mbps
PWM Modualtion
Carrier wave Pulse wave
Source
Internal/external
Modulation wave Sine, square, rising ramp, falling ramp, noise, arbitrary wave
Modulation frequency
1μHz
～
2MHz
1μHz
～
1MHz
Width deviation
0%～49.99% of pulse width
Frequency Sweep
Carrier wave Sine, square, ramp, pulse, arbitrary wave
Type Linear, logarithm, stepping, list sweep
Frequency sweep time
1ms～500s
Trigger source Internal, external rising edge, external falling edge, manual
Trigger output Close, rising edge, falling edge
Step 2 -2048 steps
Listfile
Maximum 2048 frequency points for a single file
Frequency range is accordance with fundamental wave range
Burst
Carrier wave Sine, square, ramp, pulse, arbitrary wave
Type N cycle, infinite, gated
Initial phase
0～ +360°
Period
1us～500s
Cycle number 1-50000
Gated source External trigger
Trigger source Internal, external rising ede, external falling edge, manual
Digital Protocol
SPI
Interface
CH2 - SCLK
、
CH3 - nCS
、
CH4 - MOSI
Amplitude 1mV-10V
Clock frequency
1Hz～50MHz
