UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
156
Send way Auto, manual
Interval time 20ns-1000s in auto mode of send way
Data format Hexadecimal, character
Data length Maximum 2048 bytes
IIC
Interface
CH3 - SCL、CH4 - SDA
Amplitude 1mV-10V
Clock frequency 1Hz-50MHz
Address
7bit、10bit
Send way Auto, manual
Interval time 20ns-1000s in auto mode of send way
Data format Hexadecimal, character
Data length Maximum 2048 bytes
UART
Interface CH4 - TX
Amplitude 1mV-10V
Baud rate
1-1000000（customized）
Data bit
4、5、6、7、8
Stop bit
1bit、2bit
Verify bit None,even, odd
Send way Auto, manual
Interval time 20ns-1000s in auto mode of send way
Data format Hexadecimal, character
Data length Maximum 2048 bytes
Channel Coupling&Merge
Frequency
coupling
Ratio
0.00001-10000
deviation
-600MHz
~600MHz
-200MHz
~200MHz
-400MHz
~400MHz
-160MH~
160MHz
-200MHz~
200MHz
-120MHz
~120MHz
Phase
coupling
Ratio 0.00001-10000
deviation -720°- 720°
Amplitude
coupling
Ratio 0.00001-10000
deviation
-9.999Vpp-9.999Vpp
（
50Ω
）
Channel Merge CH1 merge with CH2, CH3 merge with CH4
Sync Signal
