UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
157
Frequency range
≤60MHz（CH3 is synchronized with CH1，CH4 is synchronized with CH2
，
CH3 can’t synchronize with CH4）
Level Compatible with TTL
Output impedance
50Ω，typical value
Coupling way DC
External Modulation Input
Input frequency
＜50kHz
Modulation depth ± 5Vpk = 100%
Input impedance
5kΩ（typical value）
External Reference Input
Input frequency
10MHz±50Hz（clock frequency adjustable）
Level range Compatible with TTL
Input impedance 10kΩ (typical value, DC coupling)
Lock time
＜1s
Internal Reference Input
Input frequency 10MHz±50Hz
Level range Compatible with TTL
Level range 50Ω(typical value, DC coupling)
Trigger input
Input level Compatible with TTL
Slop Rising or falling, optional
Pulse width
＞100ns
Input impedance
＞10kΩ，DC coupling
Response time
＜1μs，typical value
Trigger output
Level Compatible with TTL
Pulse width
＞400ns，typical value
Output impedance
50Ω，typical value
Maximum frequency 1MHz
Frequency Counter
Measurement
parameter
Frequency, period, duty ratio, positive pulse width, negative pulse width
Frequency range
100mHz～800MHz
100mHz-60MHz ≥100mVrms
60MHz-300MHz ≥200mVrms
