UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
158
300MHz-500MHz ≥500mVrms
500MHz-800MHz ≥1Vrms
Coupling mode AC, DC, HF reject
Trigger level
-2.5V～2.5V
Frequency
resolution
8bit
Accuracy ±51ppm
Sensitivity 0%-100%
General Technical Specification
Display mode
10.1
寸
TFT capacitive touch
，
1280*800 resolution
Communication
interface
USB Host, USB Device, LAN、
Supply voltage
100
～
240 VAC
，
45
～
440Hz,CAT II
Power dissipation Less than 50W
Fuse wire
2A
，
T-class
，
250V
Environment
Temperature range
operating
：
10
℃～
+40
℃
Non-operating：-20℃～+60℃
Cooling method
Forced cooling by fan
Humidity range
+35℃以下：≤90% relative humidity
+35
℃～
+40
℃：
≤60% relative humidity
Altitude Operating: below 2000 meter
Non-operating
：
below 15000 meter
Machinery Specification
Size（reference）
370mm×115mm×185mm
Net weight 4.04kg
Gross weight 6.06kg
