UTG9000T Series Function Abitrary Waveform Generator
33
Tap Language to step through Chinese/English, this function requires to restart the instrument.
1. Separator
Tap to Separator to step through Comma, Space, None, and it is separator between in
parameters of channel.
2. Beep
Tap Beep to step through OFF/ON to set the sound when tap the key.
3. Backlight
Tap Backlight key to step through the light of screen of“30%, 40%, 50%, 60%, 70%, 80%, 90%,
100%”.
4. Screen Saver
Tap Screen Saver to step through OFF/5min, 15min, 30min, and 60min. The instrument will turn
off screen display as the screen saver setting, it can be call on by press any keys.
5. Clock Source
Tap Clock Source key to step through Internal/External.
Internal: supported clock source of 10MHz.
External: receive the external clock through the terminal of 10MHz In at the back panel
(frequency 10MHz, amplitude TTL).If the instrument inspect the terminal has no effect external
clock, screen will pop-out a notice “ External clock is invalid.”And display the symbol on the
top right. If the instrument inspect the terminal of external clock is effect, it displays the symbol
.
6. Clock Output
Tap Clock Output to step through OFF/ON. Turn on the clock output, the terminal of 10MHz Out
for other instrument.
The synchronization approach between the instruments:
Connect the terminal of 10MHz Out of the first instrument (Clock Output ON) with the the terminal
of 10MHz In of the other instrument (Clock source External), and set both of them at the same
output frequency to implement the sync. Multi-instrument can sync with others as the same steps.
7. Phase
Tap Phase step through Sync/Independent.
Sync: The start phase of four channels are associated.
Independent: The start phase of channel is independent.
8. Power On
Tap Powe On to step through Default, Last, Set1, Se2, Set3, Set4, and Set5.
Set the start stauts of the instrument, select the preview settings of save function.
9. Manual
