UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
72
steps as following,
1) Turn on PSK modulation mode: tap CH1→Modulate→PSK accordingly.
2) Set the parameter of the carrier wave signal
Tap Base to select sine as the carrier wave (the default option is sine), so this step has no
change.
Tap Freq to pop-out visual keyboard to enter 2kHz.
Tap Ampl to pop-out visual keyboard to enter 2Vpp.
3) Set the modulating frequency and phase
After the parameter setting of the carrier wave, tap Type to return to modulation interface to
set the modulating frequency and phase.
