Carrier wave frequency settings
Refer to The carrier wave frequency settings of AM modulation.
The PN code settings
UTG9000T function/arbitrary waveform generator can select the internal source. Turn on BPSK
modulation mode, the default PN code is PN3. Rotate multifunction knob or tap PN Code→PN3 to
select different PN code.
BPSK rate settings
In BPSK modulation mode, it can set the shift frequency between in the carrier phase and the
modulating phase. The BPSK bitrate range cam set to 1μbps~2Mbps, the default range is 100bps.
Rotate multifunction knob, push direction key or tap Bitrate tab to pop-out visual numeric keyboard
to enter values and select unit in modulation setting interface.
