UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
79
Select the carrier waveform
The carrier wave of QPSK: sine, square, ramp and arbitrarty wave (except DC), the default option
is sine wave. After select QPSK modulation, tap Base to present the carrier waveform on the right
side.
Carrier wave frequency settings
Refer to The carrier wave frequency settings of AM modulation.
The PN code settings
UTG9000T function/arbitrary waveform generator can select the internal source. Turn on QPSK
modulation mode, the default PN code is PN3. Rotate multifunction knob or tap PN Code→PN3 to
select different PN code.
