Uniden BCD436HP User Manual

23
Turning on the Scanner
Func
Menu
Scroll Control
(BCD436HP) Press and hold for about 2 seconds. If the screen is too dark,
press to turn on the backlight. Rotate the scroll control clockwise and set the
volume to around 10 o’clock. Press the scroll control to display the volume level.
Turn the scroll control (within 10 seconds) to adjust the volume. Press the scroll
control again to close the volume level (or let it disappear after 10 seconds).
Press Func then press the scroll control to display the squelch level. Turn the
scroll control counter-clockwise all the way then clockwise until the noise stops,
then one notch more. Press the scroll control again to close the squelch level.
(BCD536HP) Rotate VOL clockwise and set the volume to around 10 o’clock.
Rotate the SQ knob counter-clockwise all the way, and then rotate the VOL knob
to find a comfortable volume level. Rotate the SQ clockwise until the noise stops,
then one notch more.
The first time you turn on your scanner it will prompt you to set the clock.
See Setting the Clock.
To begin scanning right away, press the Zip button to select your country and
zip/postal code (See Data Naming to enter postcode). The scanner will load
channels for your area from the database and start scanning.

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
