Uniden BCD436HP User Manual

39
Wi-Fi Setup (BCD536HP Only)
The Wi-Fi dongle allows you to connect to the scanner wirelessly and control your
scanner with the Remote software.
The scanner has two different Wi-Fi connection modes, Infrastructure Mode and
Access Point Mode.
Infrastructure Mode is able to connect to an Access Point device.
With this mode, all you need to do is a set a password. In a few cases, there is no
password needed with the Access Point unit.
Access Point Mode is able to connect with up to 5 clients.
Setting parameters are as follows: SSID, Security type, and Password.
Wi-Fi Options
Make sure the Wi-Fi dongle is connected to the USB port behind the scanner.
Press Menu then scroll to Wi-Fi Setup and press E/yes.
Scroll to the Favorites List and press E/yes.
Scroll to Edit Favorite and press E/yes.
Show Wi-Fi Information
Shows the IP address, MAC number, and version when connected.
Shows ‘Wi-Fi not connected’.
Set Connection
Off Not connected.
Infrastructure Mode – Routers etc.
Select AP Select the access point with the encryption type.
Password See Data Naming.
Access Point Mode – Laptops, Smart devices etc.
Input SSID
Enter (or use default) name of connection. See Data Naming.
Select Security
Open, WEP, or WPA/WPA2
Input Password See Data Naming.
Reset to Factory
At Confirm Delete? Press E/yes or .no.

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
