Uniden BCD436HP User Manual

87
Fire Tone-Out
Fire-Tone-Out will monitor up to 32 different channels for paging tones (two-tone
sequential, single tone, and group tone).
Tone-Out Standby Mode is used if you know and use programmed tones.
Tone-Out Search Mode is used if you don’t know the tones.
All tone-outs (channels) that have the same frequency (and modulation and
attenuation) as the one you select will also (and only) be monitored so you can
monitor up to 32 tone-out channels for one frequency.
In this case, the scanner displays each tone-out channel for two seconds. It does
not scan them; tone-out monitors the frequency for all tone-out channels with the
same frequency.
Regardless of the current display, the scanner will alert on any received tone out
that matches a stored setting (channel) for the frequency.
Tone-Out Setup
Press Menu. Scroll to Tone-Out for... and press E/yes.
Scroll to Tone-Out Setup and press E/yes.
Scroll to Tone-Out (0-31) and press E/yes.
Edit Name
Set Delay Time
Set Frequency
Set Alert
Set Tone
Set Audio AGC
Edit Name See Data Naming.
Set Frequency
Edit Frequency Enter the frequency and press E/Yes.
Set Modulation
Auto, NFM, FM
Set Attenuator
On or Off

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
