Uniden BCD436HP User Manual

34
A Look at the Display
Top Line
appears to show Function Mode.
appears and blinks to show Function Mode is locked.
F0-9: indicates the first digit of the Favorites List quick key on the left with the
blinking second digit on the right in Scan Mode.
a non-blinking number on the right indicates the quick key is enabled waiting to
be scanned.
a - (dash) means nothing is assign to the quick key.
an * (asterisk) means the quick key is disabled.
SITE HOLD appears in Site Hold.
SEARCH appears in Search Mode.
The Time appears.
↑ or ↓ appears to show the Scan or Search Direction.
GPS appears when connected to a GPS unit.
REC appears when recording.
appears to show Wi-Fi Status in Infrastructure Mode.
! indicates Wi-Fi Mode is off.
AP appears when connected in Access Point Mode.
appears to show the signal strength.
PRI appears in Priority Mode and is reversed- in Priority DND Mode.
appears and blinks if the battery is low. (BCD436HP Only)
appears if the Close Call Priority feature is on.
is reversed in Close Call DND Mode.
S=NN shows the squelch level for three seconds when you turn SQ.
Battery Level when you press VOL. (BCD436HP Only)

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
