Uniden BCD436HP User Manual

35
A Look at the Display
2nd Line
S0-9: shows the first digit of the System quick key on the left with the blinking
second digit on the right.
a non-blinking number on the right indicates the quick key is enabled waiting to
be scanned.
a - (dash) means nothing is assign to the quick key.
an * (asterisk) means the quick key is disabled.
0-9: shows the Custom Search key status.
The Date is shown.
Receive Mode in Function Mode.
Volume Offset for the channel in Function Mode.
IFX appears if Intermediate Exchange is enabled for the channel.
ATT appears to show channel attenuation in Receiving or Hold Modes and in
Search Mode to show search attenuation.
P25 appears if the channel is receiving digitalized voice
in Receiving or Hold Modes.
LNK appears when data is received on a voice channel
in Receiving or Hold Modes.
DAT appears when data is received on a control channel
in Receiving or Hold Modes.
ENC appears if the channel is receiving encrypted voice and is muted
in Receiving or Hold Modes.
WX appears if the Weather Alert Priority feature is on.
V=NN shows the volume level for three seconds when you turn VOL.
3rd Line – 3 Line Display Off
System Name and Avoid/Hold status in Receiving or Hold Modes.
Temporary Avoids appear reversed in the display- .
Search with Scan appears to show a Custom Search in Scan Mode.
Custom Search Name in Search Mode.

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
