APX 525/625 Generator Revision C Service Adjustments
©
2005 Del Medical Imaging Corporation
7/5/2005 Page 151
AEC Inspection and Calibration
The AEC will be powered up by +/- 12 VDC from APR power module.
AEC Cable Interconnections
There are three cable connections (four with two ion chambers):
1. Generator Power Module to AEC Main chassis (power and signals)
2. Generator Control to AEC Main chassis (signals). The standard length is 45 feet
3. and 4. Ion chamber to AEC main chassis. The standard length is 40 feet
CONNECTIONS FOR ION CHAMBERS ON MAIN AEC BOARD
J1- TABLE
J2 - WALL
