Universal APX 525 - System Weights and Dimensions

APX 525/625 Generator Revision C Operating Manual
© 2005 Del Medical Imaging Corporation
7/5/2005 Page 21
RAD 56 - 0.6 X 1.2
RAD 60 - 0.6 X 1.2
RAD 68 - 0.6 X 1.2
RAD 68 - 1.0 X 2.0
RAD 74 - 0.6 X 1.5
Toshiba
DR-3724H - 0.6 X 1.2
UX-51H39 - 0.6 X 1.2
UX-51H42 - 0.6 X 1.5
Eimac
A119 - 1.0 X 2.0
A132 - 0.6 X 1.2
A272 - 0.3 X 0.7
A292 - 0.6 X 1.2
Dunlee
DU303M - 1.0 X 2.0
PX-1312 - 0.6 X 1.2
PX-1429 - 0.6 X 1.2
PX-1436 - 0.6 X 1.2
Comet
DX39H - 0.6 X 1.5
Consult Del Medical Imaging technical support for tubes that are not listed.
Automatic Exposure Control: Universal Model 110-0085G6
SYSTEM WEIGHTS AND DIMENSIONS
Component Weight
Control Console (with floor stand) 30 lbs. (14 kg)
Power Module 104 lbs. (47.3 kg)
High Tension Transformer (Single Tube) 128 lbs. (58 kg)
3 Phase Line Match Transformer 120 lbs. (55 kg)
Rack Cabinet with System Components Installed 500 lbs. (227 kg)
