Universal APX 525 - Identification of Incoming Line

APX 525/625 Generator Revision C Pre-Installation
© 2005 Del Medical Imaging Corporation
7/5/2005 Page 28
NOTE: The minimum wire sizes listed above have been selected for the maximum
wire resistance allowed at maximum momentary full load current. To meet National
Electric Code Specifications, you must select a wire type having an amperage rating
of at least 50% of the generator’s peak current demand. Rating also applies to the
selection of fuses or circuit breakers.
Identification of Incoming Line
An initial evaluation of the incoming line should have been performed during the pre-
sales site survey, prior to placing the actual order to purchase the x-ray generator
from Del Medical Imaging X-Ray. At that time, the physical configuration of the
generator (i.e. Single Phase or Three Phase line input) had to have been made.
The installer must now ensure that the configuration is accurate and that the
correct parts have been received.
All wiring up to the APX 525/625 power module input terminals is to be furnished by
the customer.
All electrical wiring must conform to state and/or local electrical codes. Aluminum
wire is unacceptable for use in wiring.
Note:
The minimum voltage measured at the input terminals of the power module
must not fall below 224 VAC during any exposure.
Warning: Lethal voltages may be present.
These instructions are intended for use by qualified installers only.
Never work on energized circuits during this installation unless
specifically instructed to do so.
