APX 525/625 Generator Revision C Installation
©
2005 Del Medical Imaging Corporation
7/5/2005 Page 97
Cable Index
Cable # Description Length Part Number
1 Main Power (not supplied)
2
High Power Line Match to Power
Module – Single Phase
8 feet (2.4 m) 126-0214G2
2
High Power Line Match to Power
Module – Three Phase
8 feet (2.4 m) 126-0208G2
3
Low Power Line Match to Power
Module
8 feet (2.4 m) 126-0211G1
4 Operator Control Cable 45 feet (13.7 m) 126-5174G1
5 AEC Control Cable 45 feet (13.7 m) 126-5178G1
6 AEC Interface Cable 10 feet (3.0 m) 126-0204G1
7 Table Power (not supplied)
8 Electric Lock Power (not supplied)
9 Collimator Power (not supplied)
10 Wall Stand Power 40 feet (12.2 m) 4465-0118
11 Wall Cassette Size Sense Cable 40 feet (12.2 m)
(supplied with
collimator)
12
Table Cassette Size Sense
Cable
40 feet (12.2 m)
(supplied with
collimator)
13 Collimator Control Cable 40 feet (12.2 m)
(supplied with
collimator)
14 Wall Ion Chamber Cable 45 feet (13.7 m)
(supplied with
ion chamber)
15 Table Ion Chamber Cable 45 feet (13.7 m)
(supplied with
ion chamber)
16 Stator Cable 40 feet (12.2 m)
(supplied with
x-ray tube)
17 kV/mA Feedback Cable 8 feet (2.4 m) 126-0177G1
18 HV Primary Cable 8 feet (2.4 m) 126-0179G1
19 Filament Cable 8 feet (2.4 m) 126-0178G1
20 High Tension Cables (two)
(Specify length)
21 Wall Bucky Cable 20 feet (6.1 m) 5500-2299
22 Table Bucky Cable 20 feet (6.1 m) 5500-2399
Cable Index Notes
1. AEC Devices are optional
2. Items 19, 20, and 21 must remain 8 feet ONLY
3. Observe local codes with respect to wire size and grounding requirements
4. The Generator requires a dedicated power line
5. Use Copper wire only, aluminum wire is unacceptable
To Next Page
