APX 525/625 Generator Revision C Service Adjustments
©
2005 Del Medical Imaging Corporation
7/5/2005 Page 152
Figure 74 - Test Points
AEC COMMUNICATION LINK CHECKOUT
This test will verify the correct selection of modes of operation, fields, densities, and
desired kilovolts between the controller and the AEC device.
Test Point 9
Test Point 7
Test Point 15
Test Point 8
Test Point 6
Ground
Test Point 2
Test Point 3
Test Point 4
To Next Page
