APX 525/625 Generator Revision C Operating Manual
©
2005 Del Medical Imaging Corporation
7/5/2005 Page 20
72-86 8 inches (20.32 cm) .2 OD (Optical Density)
90-125 10 inches (25.4 cm) .25 OD (Optical Density)
Default Termination Operator selectable
Screen/film speed-factory preset Screen 1: - 200
Screen 2: - 400
kV Compensation 5 calibration points: - 40, 56,72,90,125 kV
SID range: 36 to 72 inches. (91.44 cm to 182.88 cm)
Ion Chamber/preamplifier
Ion chamber voltage 200 VDC +/-5% internally generated
Input voltage +12 VDC, -12 VDC
Sensitivity Film/screen combinations 100-500
Maximum output 8.5 VDC
Linearity +/-5%
Field sizes
Center field 2" x 4.4" (5.08 cm x 11.17 cm)
Left/Right 2.2" x 3.6" (5.58 cm x 9.14 cm)
Dimensions
Control/display Incorporated into generator
Main Chassis 10.4" x 16.75" x 3.06" (incorporated into the
rack cabinet) (26.4 cm x 42.5 cm 7.7 cm)
Regulatory Conformance
Meets the requirements of 21 CFR, section
1020.31
COMPATIBILITY LISTING
The following certified components have been found to be compatible with the APX
525/625.
X-Ray Tube Assemblies
Varian RAD 8 - 1.0 X 2.0
RAD 13 - 1.0 X 2.0
RAD 14 - 0.6 X 1.2
RAD 16 - 1.0 X 2.0
RAD 21 - 0.6 X 1.2
RAD 25 - 1.0 X 2.0
RAD 40 - 0.6 X 1.2
