APX 525/625 Generator Revision C Operating Manual
©
2005 Del Medical Imaging Corporation
7/5/2005 Page 5
OPERATING MANUAL
Introduction
The Universal APX is a high frequency, microprocessor based x-ray generator,
which is designed for general radiographic applications. The operator’s control
features a unique menu driven, soft button interface that makes it extremely easy to
use.
Caution: If your machine is setup for password protection, write
down what your password is and store it in a safe place. If you forget
your password, you will have to send the control console back to the
factory to get it reprogrammed. The installation technician will tell
you if your machine has password protection or not.
The APX can be operated in the following modes:
• 2 Point Mode: Operator controls kV and mAs of exposure. mA is
automatically calculated by software to produce highest allowable tube
current for shortest possible exposure, within limitations of the x-ray
tube.
2 Point Operator’s screen
