Document Box
6-7
6
Form Overlay from Custom Boxes
This function allows you to retrieve images (image files), overlay them into documents stored in custom boxes
and then print the results.
Use the procedure below.
1 Press the Document Box key.
2 Press [Custom Box], select the box containing the
document you want to overlay the image into and
print, and then press [Open].
NOTE: If a custom box is protected by a password,
enter the correct password.
3 Select the document you wish to print by checking
the checkbox.
The document is marked with a checkmark.
NOTE: To deselect, press the checkbox again and
remove the checkmark.
4 Press [Print].
5 Press [Functions], [Form Overlay], [Select Stored
Form], and then [Select Form].
NOTE: You can select the form density setting through
4 levels from 10%, 20%, 30% or 100%. Press the [+] or
[-] buttons in Density.
6 In Form Overlay - Select Form, select the image file
to be overlaid onto the document from the
displayed document boxes.
You can only select one image file.
7 Press [OK].
8 Press [OK] again to return to the Functions screen.
9 Press the Start key. Printing begins.
To Next Page
