Management
11-13
11
1 Press the System Menu key.
2 Press [User Login/Job Accounting].
3 If user login administration is disabled, the user
authentication screen appears. Enter your login
user name and password and then press [Login].
For this, you need to login with administrator
privileges. Refer to Adding a User on page 11-5 for
the default login user name and password.
4 Press [Next] of User Login Setting, [Change] of
Obtain NW User Property.
5 Press [On].
6 Press [Server Name].
7 Enter the LDAP server name or the IP address and
press [OK].
8 Press [# keys] to enter the LDAP port number using
the numeric keys.
9 Press [Name 1].
10 Enter the LDAP Attribute to obtain the user name to
be displayed and press [OK].
11 Follow steps 9 and 10 above to set Name 2.
12 Press [E-mail Address].
13 Enter the LDAP Attribute to obtain the e-mail
address and press [OK].
14 Press [Search Timeout] to set the amount of time to
wait before time-out.
15 Press [+], [-] or the numeric keys to enter the time.
16 Press [LDAP Security] to select the type of
encryption according to the type of security
employed by the LDAP server.
17 Select [Off], [LDAP over SSL], or [LDAPv3/TLS]
and press [OK].
To Next Page
