Default Setting (System Menu)
8-52
Detailed Adjustment
A total of 5 color pattern pages (No. 1 to 5) are printed during detailed adjustment. As with normal adjustment
(page 8-51), the printed color patterns are read sequentially during detailed adjustment.
Use the procedure below to carry out detailed adjustment.
1 Press the System Menu key.
2 Press [ ], [Adjustment/Maintenance], [ ] and
then [Next] of Gray Adjustment.
3 Press [Detail].
4 Press [Execute]. A color pattern is printed.
Check that the number "1" is printed at the bottom
of the color pattern.
5 As shown in the illustration, place the printed side
down on the platen with the three black boxes
aligned to the top.
6 Press [Execute]. The color pattern is read and
adjustment begins.
The second color pattern is printed.
7 Check that the number "2" (to "5") is printed at the
bottom of the color pattern and repeat steps 5 to 7
four times to read color patterns 2, 3, 4 and 5 in
sequence.
8 Press [OK] in the adjustment end confirmation
screen.
Color Calibration
After prolonged use, or from the effects of surrounding temperature or humidity, the hue of printed color output
may shift or color drift may occur. Using this function enables printing in the most appropriate color by adjusting
hue and color drift in detail. Use gray adjustment when the color is not enhanced even after performing color
calibration (see page 8-51). If the hue and color are not enhanced, use color registration (see page 8-47).
1 Press the System Menu key.
2 Press [ ], [Adjustment/Maintenance], [ ] and then [Next] of Color Calibration.
3 Press [Execute]. Color Calibration begins.
4 Press [OK] after Color Calibration is complete.
To Next Page
