Default Setting (System Menu)
8-48
1 Press the System Menu key.
2 Press [ ], [Adjustment/Maintenance], [ ] and
then [Next] of Color Registration.
3 Press [Print] of Chart. A chart is printed.
On the chart, for each of M (magenta), C (cyan) and
Y (yellow), 3 chart types are printed on one sheet:
H-F (left), V (right), H-R (horizontal).
Chart Example
4 Find the location on each chart where 2 lines most
closely overlap each other. If this is the 0 position,
registration for that color is not required. For the
illustration, B is the appropriate value.
5 Press [Next] of Registration.
6 Press [Change] for the chart to be corrected.
7 Press [+] or [-] to enter the values read from the
chart and press [OK].
Press [+] to increase the value from 0 to 9. To
decrease, press [-].
By pressing [-], the value changes from 0 to
alphabetic letters, going from A to I. To move in the
reverse direction, press [+].
To Next Page
