Part Names
1-6
31 Top Tray
32 USB Memory Slot (A1)
33 Paper Feed Unit Cover
34 Paper Feed Unit
35 Green Knob
36 Paper Width Adjusting Tab
37 Paper Length Guide
38 Handles
39 Multi Purpose Tray
40 Paper Width Guide
41 Option Interface Slot (OPT2)
42 USB Port (A2)
43 Network Interface Connector
44 USB Interface Connector (B1)
45 Option Interface Slot (OPT1)
46 Main Power Switch
36
41
42
43
44
46
32 31
37
38
39
40
35
34 33
45
