Vacon 100X series User Manual

3
vacon • 7 Startup
Push the OK button unless you want to set all parameter values manually.
If you set Motor Type to Induction Motor, you see the next question. If your selection is PM Mo-
tor, the value of parameter P3.1.1.5 Motor Cos Phi is set to 1.00 and the wizard goes directly to
question 18.
6
Run Startup Wizard?
Yes
No
7
Make a selection of an application
(P1.2 Application,ID212)
Standard
Local/Remote
Multi-step speed
PID control
Multi-purpose
Motor potentiometer
8
Set a value for P3.1.2.2 Motor
Type (so that it agrees with the
nameplate)
PM motor
Induction motor
9
Set value for P3.1.1.1 Motor Nom
Voltg
(according to nameplate)
Range: Varies
10
Set value for P3.1.1.2 Motor Nom
Freq
(according to nameplate)
8.00...320.00 Hz
11
Set value for P3.1.1.3 Motor Nom
Speed
(according to nameplate)
Range: 24...19.200 rpm
12
Set value for P3.1.1.4 Motor Nom
Currnt
(according to nameplate)
Range: Varies
13
Set value for P3.1.1.5 Motor Cos
Phi
(according to nameplate)
Range: 0.30...1.00
14
Set value for P3.3.1.1 Minimum
frequency reference
Range:
0.00...50.00 Hz
15
Set value for P3.3.1.2 Max-
FreqReference
Range:
0.00...320.00 Hz
16
Set value for P3.4.1.2 Accel Time
1
Range:
0.1...300.0 s
17
Set value for P3.4.1.3 Decel Time
1
Range:
0.1...300.0 s

Vacon 100X series Specifications

General

Product series	Vacon 100X
Category	Controller
Protection Class	IP66 / Type 4X
Frequency	50/60 Hz
Braking Chopper	Built-in
Ambient Temperature	-10°C to +40°C, up to +50°C with derating
Control Method	Vector control
Input Voltage	525-690V
Communication Options	CANOpen
Mounting	Wall-mounted
EMC Filter	Built-in
Cooling Method	Air-cooled
Protection Features	Overtemperature, Overvoltage, Undervoltage
