13. TERMBOX Installation
13.1 Overview of TERMBOX Installation
TERMBOX is not used when the automatic weather station contains a solar panel or a
radio.
For AWS310, TERMBOX-1212 is available.
For AWS310-SITE, TERMBOX-1200 is available for 1 data line and TERMBOX-1212 for 2 data
lines.
More Information
‣
Placing TERMBOX (page 169)
‣
Installing TERMBOX on Pole Mast (page 170)
‣
Installing TERMBOX on Frangible Lattice Mast (page 172)
‣
Grounding TERMBOX (page 173)
‣
Grounding TERMBOX Signal Cable (page 174)
13.2
Placing TERMBOX
The distance between the termination box and sensor input must not
exceed 5 meters (16 ft 5 in) along the cable.
CAUTION!
The TERMBOX delivery includes APPK-SET mounting kits of dierent sizes. Use the clamp
best suited to your mast.
To prevent corrosion and oxidation, use copper paste or equivalent on screws and
connector threads.
Chapter 13 – TERMBOX Installation
169
