To avoid strain on the connector, make sure you connect the cable properly.
Too much strain may cause the cable to fall
o, damage the cable or connector, or make
the cable or connector susceptible to water leakage.
CAUTION!
• Pipette
• Cable cutters
• Cable stripper
Figure 68 Enclosure Bottom View, Rubber Flange
1 Hole for antenna protection module
2 Enclosure pressure compensation device
3 Service port (maintenance terminal connection)
4 Flange for sensor cable connections
5 Hole for static pressure head
6 Flange for AC (mains) current (and possible extra sensor cable connections)
AWS310/AWS310-SITE Installation Manual M211584EN-F
220
