9. Solar Panel Installation
9.1 Overview of Solar Panel Installation
Photovoltaic modules generate direct current (DC) when exposed to
sunlight or other sources of light. Although single modules produce low voltage and
current, contact with module output wiring can cause shocks and burns.
WARNING!
Handle the solar panel with care. Impact on the front or rear surface can
damage the module. Do not bend the panel.
CAUTION!
When working with the solar panel, use properly insulated tools and wear
rubber gloves.
CAUTION!
The sun rays must be perpendicular to the solar panel (sunlight must hit the solar panel at
a 90° angle).
Do not concentrate light on the panel in an attempt to increase its power output.
More Information
‣
Installing Solar Panel (page 85)
‣
Adjusting Solar Panel Tilt Angle (page 87)
9.2
 Installing Solar Panel
5‑mm Allen key
Chapter 9 – Solar Panel Installation
85
