A.4.3 AWS310-SITE Optional Telemetry

Power connections X1

+24VDC

+24V Sensor Heating

+12VDC ,GND

See drawing 1

Telemetry options

QSP431

SURGE

PROTECTOR

RS-485

MOD1_2

QSP431

SURGE

PROTECTOR

RS-232

MOD2_2

45 46 47 48 49

11 12

Signal

Terminal strip

Not included in the basic structure

DXL421

1 3 5

8 10 12

2 4 6

7 9 11

PT 2

TELE-

DSI486 Default settings fo AWS310-SITE

MOD1 Port 2 RS485

MOD2 Port 2 RS232

Figure 88 AWS310-SITE, Optional Telemetry

AWS310/AWS310-SITE Installation Manual M211584EN-F

254
