MM101 – D-4E HOT MELT UNIT 4
VALCO MELTON S.L.U. Pol. Ind. Agustinos C/G 34 3116 0 ORCOYEN, NAVARRA
TEL: +34 948 321580 Fax: +34 948 326584 melton@melton.es www.valcomelton.com
TABLE OF CONTENTS
Section 1 – Introduction 7
Description 7
Section 2 – Safety Information 8
General Information 8
Warnings 8
Cautions 10
What to Do if Contact with Hot Adhesive Occurs 10
What to Do if Adhesive-Related Fire or Explosion Occurs 10
What to Do if Inhalation of Adhesive Fumes Occurs 11
Section 3 - Basic Features 12
Key Features 12
Section 4 - Installation 13
Choosing a Location 13
Mounting Footprint 14
Routing Low-Voltage Leads 15
Connecting the Electrical Power 15
Connecting the Hoses 19
Connecting the Hot Melt Hoses to the Applicators 23
Installing the Pneumatic Pressure Relief Valve Option 25
Wiring Diagram 27
Customer Connections 28
Section 5 – Setup 30
Control Panel 30
Power On/Off and Standby Mode 32
Navigation 33
Memory Storage 33
Editing 34
Thumbwheel vs. Single Digit Edit 34
Entering Passwords 35
Set Language 36
Set Temperature Units 38
Programming Temperaturas 39
Temperature Screens 39
Tank Temperature 40
Hose/Valve Temperature 41
System Ready Temperatura 43
Ready Delay Time 44
Over Temperature Alarm 45
Under Temperature Alarm 46
Maximum Temperature 47
Automatic Pump Mode 48
Setback Temperature 49
